Elite Smartphone
1 / 5
Specifically designed and manufactured to provide CRYSTAL CLEAR communications to help create a safer work environment, which increases PRODUCTIVITY and lowers the risk of LIABILITY.
Floor Installation: Connect the intercom with the accessory power cable. A dedicated power device can drive up to twenty units. The protective ground wire passes through the coupler hole to the ground. Note: Do not ground in the middle ground.
Cage Installation: In the lift cage, connect the intercom, power supply, and coupler. Ensure the protective ground wire passes through the coupler hole and is properly connected with the ground.
| Terminal NO | Label | Cable Description | Notes |
|---|---|---|---|
| 1 | L | Power (Blue) | Three-core cable |
| 2 | N | Power (Brown) | |
| 3 | G | Ground (Yellow) | |
| 4 | -V | Cable Shield | Four-core shielded cable |
| 5 | -V | Negative Power (Brown) | |
| 6 | +V | Positive Power (Black) | |
| 7 | +V | Positive Power (Blue) |
